Schreiber Engineering 100AC Air Cooled Water Chiller 20 GPM 1 Ton 230VAC
The Schreiber Engineering 100AC is a self-contained, air cooled recirculating water chiller with a 1-ton (12,000 BTU/hr) refrigeration capacity and a 1/2 HP fluid circulating pump. It runs on 230VAC single-phase power and is mounted on casters for easy repositioning on a shop floor. This unit has been tested at our facility and successfully chilled room-temperature water to 55°F (13°C) in a closed-loop test. There are several known defects — please read the full condition details below before purchasing.
Specifications & What's Included
- Model: Schreiber Engineering 100AC
- Cooling Capacity: 1 Ton / 12,000 BTU/hr
- Power Input: 230VAC, Single Phase, 17.2 FLA
- Fluid Circulating Pump: 1/2 HP
- Fluid Flow Rate: 20 GPM @ 24.8 PSI
- Fluid Reservoir Capacity: 20 Gallons
- Refrigerant: R22
- Compressor: Tecumseh AJ600FT-205-J7, 208–230V, 1-Phase, 60 Hz, LRA 41.0
- Compressor Oil: Synthetic Alkylate
- Thermostat/Temperature Controller: Johnson Controls dial thermostat (side-mounted)
- Front Panel Controls: Compressor on/off switch, Water Pump on/off switch
- Fluid Connections: Tank Fill, Return, and Discharge ports on front panel
- Condenser: Air-cooled top-mounted fan with wire guard
- Dimensions: 37" L × 29" W × 42" H
- Mobility: Four casters (floor-rolling)
- ETL Listed
- Made in USA
- Known Defects:
- Front panel temperature gauge is broken — needle is stuck at its lowest position
- Front panel indicator lights for compressor and water pump do not illuminate
- Significant rust on the exterior surface of the reservoir tank (tank is water-tight)
Applications
Air cooled recirculating chillers like the Schreiber 100AC are used in industrial and laboratory settings where a stable supply of cooled process water is needed without a dedicated cooling tower or building chilled-water loop. Typical applications include cooling laser systems, CNC machine spindles and hydraulics, injection molding equipment, welding equipment, vacuum systems, electron microscopes, and laboratory reactors. The self-contained, air cooled design makes this type of unit well-suited for smaller facilities or standalone process equipment — the unit rejects heat directly to the surrounding air through the condenser fan rather than requiring external water cooling. With a 20 GPM pump and 20-gallon reservoir, the 100AC is sized for moderate industrial process loads up to 1 ton. Units like this are commonly found in machine shops, university labs, semiconductor facilities, and light manufacturing environments.
This Schreiber Engineering 100AC Air Cooled Water Chiller has been tested at our facility and successfully chilled room-temperature water to 55°F (13°C) in a short closed-loop test. The compressor and water pump both operate, and their respective power switches function correctly. There are several known defects to be aware of: the front panel temperature gauge is broken and stuck at its lowest position; the front panel indicator lights for the compressor and water pump do not illuminate; and there is significant rust on the exterior of the reservoir tank. The tank is water-tight despite the external rust. The exterior cabinet shows overall wear including paint scuffs and dents consistent with age and industrial use. This unit ships via freight only due to its size and weight (432 lbs). Please review our full photo set for a detailed look at the condition and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Schreiber |
Model: |
100AC |
MPN: |
100AC |
Type: |
Air Cooled Water Chiller |
SKU: |
44839 |
Cooling Capacity: |
1 Ton (12,000 BTU/hr) |
Flow Rate: |
20 GPM @ 24.8 PSI |
Fluid Reservoir Capacity: |
20 Gallons |
Pump Power: |
1/2 HP |
Voltage: |
230VAC, Single Phase |
Full Load Amps: |
17.2 FLA |
Frequency: |
60 Hz |
Refrigerant: |
R22 |
Compressor: |
Tecumseh AJ600FT-205-J7, 208-230V, 1PH, R22 |
Compressor Oil: |
Synthetic Alkylate |
Cooling Method: |
Air Cooled |
Power Requirements: |
230VAC, 1-Phase, 17.2 FLA |
Dimensions: |
37" L x 29" W x 42" H |
Country/Region of Manufacture: |
United States |
Form Factor: |
Floor Standing / Mobile (Caster-Mounted) |
Seller Notes: |
Unit only — no additional accessories included. Freight shipping required. |
Condition Notes: |
Schreiber Engineering 100AC Air Cooled Water Chiller tested and chilled to 55°F. Compressor and pump operate. Known defects: broken front gauge, non-illuminating indicator lights, exterior tank rust (tank is water-tight). Freight shipping required. |
