Description
Powell Lot of 45 Stainless Steel Flanged Gate Valves & Fittings 150 A182
This lot consists of 45 individual stainless steel flanged gate valves and pipe fittings from Powell and several other industrial valve manufacturers. The lot includes a variety of flange sizes, port openings, and pressure class ratings, making it useful for sourcing multiple sizes at once or for MRO and replacement applications. All pieces are stainless steel construction with flanged end connections.
Specifications & What's Included
- Total quantity: 45 pieces
- Material: Stainless steel body and fittings throughout
- End connection: Flanged
- Valve type: Gate valves (majority) and pipe flange fittings
- Qty 6 – Powell: 4-1/4" flange, 1-1/8" port opening
- Qty 3 – Powell: 3-3/4" flange, 3/4" port opening
- Qty 2 – Powell: 3-1/2" flange, 3/4" port opening
- Qty 2 – Powell: 2-1/2" flange, 3/4" port opening
- Qty 3 – Aloy Co.: no flange, 3/4" port opening
- Qty 2 – Aloy Co.: 3-1/2" flange, 3/4" port opening
- Qty 1 – Aloy Co.: 4-1/4" flange, 1" port opening
- Qty 1 – Aloy Co.: 4-1/4" flange, 1" port opening
- Qty 1 – Aloy Co.: no flange, no base
- Qty 1 – Jenken: 4" flange, 3/4" port opening
- Qty 2 – NewCo.: 4" flange, 3/4" port opening
- Pressure class ratings present in lot: 150, 300 (see class markings below)
- Class / rating markings on individual pieces: (3) 150 B16, (1) 150 17474, (2) 2-150, (1) 150 S10 A182, (1) 150-6 A182, (8) 1 150, (8) 3/4 150, (1) 1, (4) 1/2 150, (1) 1/8, (2) 1/2, (1) 1/4 3/8 150, (2) 4, (1) 1 300, (9) 150 M14, (1) 150
- Overall lot dimensions: approximately 28 x 22 x 18 inches
- Approximate lot weight: 450 lbs — freight shipping required
- Individual pieces may be available — contact us for details
Applications
Flanged stainless steel gate valves in the 150-class pressure rating are standard components in industrial piping systems where corrosion resistance and full-bore flow control are needed. They are commonly used in chemical processing, food and beverage, pharmaceutical, water treatment, oil and gas, and general industrial plant piping. The ANSI 150 pressure class is one of the most widely used flange ratings in process piping, conforming to ASME B16 standards, and A182 stainless material designations indicate forgings or fittings made to ASTM A182 specifications — commonly found in higher-integrity process piping. A mixed lot of this type is well-suited for maintenance, repair, and operations (MRO) inventory, plant shutdowns, or pipeline replacement projects where multiple sizes and types are needed at once. Powell is a well-established American valve manufacturer with a long history of supplying industrial gate, globe, and check valves for process and utility piping applications.
This Powell lot of 45 stainless steel flanged gate valves and fittings has been inspected and appears to be in good used condition overall. The valves were pulled from a working environment where they were previously in service. Photos show surface rust and oxidation on several handwheels and valve stems — typical of stainless steel hardware that has been in industrial service — while the stainless bodies and flanges remain structurally sound. Some flange faces and pipe fittings show light surface discoloration and handling marks consistent with normal use. The lot includes pieces from Powell, Aloy Co., Jenken, and NewCo. in a variety of flange sizes and port openings; condition will vary by individual piece. This is a large, heavy lot (approximately 450 lbs) and requires freight shipping. Please contact us for a freight quote, to arrange local pickup, or to schedule a viewing at our facility. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Powell |
Model: |
150 Class Flanged Gate Valve |
Type: |
Gate Valve & Pipe Fittings Lot |
SKU: |
47167 |
Condition: |
Used – Pulled from Working Environment |
Material: |
Stainless Steel |
Pressure Class: |
150 (majority); some 300 class |
Material Standard: |
A182 |
End Connection: |
Flanged |
Flange Size Range: |
2-1/2" to 4-1/4" flange OD |
Port Opening Range: |
3/4" to 1-1/8" |
Lot Quantity: |
45 pieces total |
Brands Included: |
Powell, Aloy Co., Jenken, NewCo. |
Standards / Ratings: |
ANSI B16, 150 class, A182, 2-150, 150 S10 |
Shipping: |
Freight required — contact seller for quote |
Seller Notes: |
Lot of 45 mixed valves and fittings; contact us for individual pieces or details |
Country/Region of Manufacture: |
United States |
Condition Notes: |
Lot of 45 Powell & mixed SS flanged gate valves and fittings, inspected, pulled from working environment. Surface rust on some handwheels/stems; SS bodies and flanges structurally sound. Condition varies per piece. ~450 lbs, freight required. |
