The Parker Compumotor AXL-Drive is a self-contained microstepping drive from the Compumotor AX Series, featuring a built-in indexer for stand-alone or host-commanded stepper motor control. Manufactured by Parker Hannifin's Compumotor Division, it accepts AC power directly and drives 2-phase stepper motors with microstepping resolution for smooth, precise motion. The built-in indexer allows the unit to accept CW/CCW step and direction commands or execute stored motion profiles without a separate controller.

Specifications & What's Included

• Brand: Parker Hannifin — Compumotor Division
• Model: AXL-Drive (AX Series)
• Drive type: Microstepping (2-phase stepper motor drive)
• Built-in indexer: Yes — Indexer terminal block with opto-isolated I/O, CW/CCW inputs, MONO output
• Encoder input: Yes — dedicated Encoder terminal block (differential A/B/Common/Shield)
• AC power input: Terminal block on front panel (LINE, GND, N.C., NERT)
• Motor output: Terminal block on front panel (B+/B-)
• Status indicators: TR (trip), POWER, FAULT LEDs on front face
• Cooling: Passive — integral aluminum heat sink fins along left side
• Form factor: Enclosed panel-mount / chassis-mount unit
• Manufacture date code: 8928 (Week 28, 1989) — made in USA
• Included: Drive unit only — no cables, no mounting hardware
