Pacific Precision Labs DBSA 3-Axis Stage Controller Compumotor DB-Drive 115V
3-axis stepper motor stage controller with integrated Parker Compumotor DB-Drive for controlling linear positioning stages. Operates on 115 VAC, 3 Amp power supply.
Specifications & What's Included
- 3-Axis control (X, Y, Z) with dedicated indexer channels
- Internal Parker Compumotor DB-Drive
- Signal Transformer 68-2 and Comair Rotron cooling fan
- Multi-pin military-style circular connector
- Rackmount/benchtop form factor
- Includes attached cabling and internal components as shown
Applications
This controller type was used for precision motion control in laboratory and industrial settings, driving stepper motors on linear stages for XYZ positioning tasks. Commonly integrated into Pacific Precision Labs positioning systems and compatible with their stage hardware. Typical applications include microscopy automation, material testing, and automated assembly.
Condition: Used
Pacific Precision Labs DBSA 3-Axis Stage Controller with Compumotor DB-Drive, 115V. This is a used unit in fair cosmetic condition — the front panel is clean with minor surface marks, and the black chassis shows some scuffing and paint wear from age. All three indexer connectors (X, Y, Z) are present and intact, along with the Parker Compumotor DB-Drive module, Signal Transformer 68-2, and Comair Rotron fan. Internal components are visible and appear sound. A multi-pin military-style circular connector is attached to the cabling.
Pacific Precision Labs DBSA 3-Axis Stage Controller with Compumotor DB-Drive, 115V. This is a used unit in fair cosmetic condition — the front panel is clean with minor surface marks, and the black chassis shows some scuffing and paint wear from age. All three indexer connectors (X, Y, Z) are present and intact, along with the Parker Compumotor DB-Drive module, Signal Transformer 68-2, and Comair Rotron fan. Internal components are visible and appear sound. A multi-pin military-style circular connector is attached to the cabling.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Pacific Precision Laboratories |
Model: |
DBSA 3-Axis |
MPN: |
DBSA |
Secondary Model: |
DB-Drive |
SKU: |
25716 |
Type: |
3-Axis Stepper Motor Stage Controller |
Condition: |
As-Is / For Parts or Not Working |
Power Requirements: |
115 VAC, 3 Amp |
Number of Axes: |
3 (X, Y, Z) |
Indexer Channels: |
3 — Indexer X, Indexer Y, Indexer Z |
Internal Drive: |
Parker Compumotor DB-Drive |
Internal Transformer: |
Signal Transformer 68-2 |
Internal Fan: |
Comair Rotron SU2A1, 115V |
Connector Type: |
Multi-pin military-style circular connector |
Form Factor: |
Rackmount / Benchtop |
Country/Region of Manufacture: |
USA |
Seller Notes: |
Sold AS-IS for parts or repair. Includes attached cabling and internal components as shown. |
Compatible With: |
Pacific Precision Laboratories linear positioning stages |
Application: |
Linear stage motion control, stepper motor indexing |
Condition Notes: |
Used, fair cosmetic condition with minor surface marks and age-related scuffing. All connectors and internal components present and intact. |
