Optimum Electronics PG404 Pattern Generator Baud Rate Distortion Bias Tester
Handheld pattern generator and distortion tester used for telecommunications and data communications testing. Measures baud rate, start-stop distortion, and bias distortion in serial data transmission systems.
Specifications & What's Included
- Baud rates: 150, 300, 600, 1200
- Data modes: Mark, Space, SW (Switching)
- Pattern modes: 5 Level, 8 Level, RLY, Mark, Space
- Percent distortion settings: 0, 12.5, 25, 37.5
- Measurements: Baud rate, start-stop distortion, percent distortion
- Power: AC or battery selectable
- Connectors: SIG (red banana), GND (black banana), Low Level, Neutral, Loop
- AC and LP trimmer adjustments on right side panel
Applications
This device was used in telecommunications and data communications environments for testing start-stop distortion in serial transmission lines. Typical applications included modem testing, telecom line conditioning, and data circuit verification during the analog and early digital era.
Condition: Used
This Optimum Electronics PG404 Pattern Generator has been inspected and appears to be in good used condition. The front panel controls — including the rate selector (150, 300, 600, 1200 baud), data type buttons, pattern buttons, and percent distortion keys — are all present and intact. The housing shows light surface wear consistent with normal bench use; no cracks or major damage are visible. The bottom connector panel with SIG, GND, Low Level, Neutral, and Loop jacks is present and appears undamaged. Note that this unit carries a special calibration covering Baud Rate and Distortion only, last performed on 07-17-2003. Please view our photo set and contact us if you have any questions.
