Nordiko Limited N601109EE Extender Board No Jumpers PCB Card Module
The Nordiko Limited N601109EE is a printed circuit board (PCB) extender card manufactured by Nordiko Limited, a UK-based company known for producing equipment used in thin-film deposition and semiconductor processing systems. This extender board is designed to allow a mating card or module to be physically extended outside its chassis or backplane slot, enabling in-circuit debugging, probing, and troubleshooting of live signals without removing the card from the system. No jumpers are installed on this board.
Specifications & What's Included
- Manufacturer: Nordiko Limited
- Part Number: N601109EE
- Type: PCB Extender Board / Card Module
- Jumpers: None installed
- Primary connector: Gold-pin multi-pin edge connector (visible on one end)
- Secondary connector: Multi-pin connector on opposite end
- On-board components: Multiple blue trim potentiometers along top edge
- Ejector handles: Two black plastic ejector levers for chassis insertion/extraction
- PCB color: Green
- Form factor: Card / board module
- Country of manufacture: United Kingdom
Applications
Extender boards like the N601109EE are used by service engineers and technicians to diagnose faults in embedded card-based systems. By seating the extender in the target backplane slot and plugging the card under test into the extender's connector, the card is electrically connected to the system while being physically accessible — allowing oscilloscope probing, logic analysis, and component-level testing on live signals. Nordiko Limited produced equipment primarily for physical vapor deposition (PVD) and sputtering systems used in semiconductor and data storage manufacturing, and extender boards of this type are most commonly used in the maintenance and repair of those systems. They are also useful to any engineer working with similar proprietary backplane architectures who needs hands-on access to a running card without disassembling the system.
This Nordiko Limited N601109EE Extender Board has been inspected and is in good condition. The PCB is clean with no visible damage, broken traces, or missing components. No jumpers are installed on the board. The gold-pin edge connector and secondary connector both appear intact and undamaged. Black ejector handles are present and functional. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Nordiko Limited |
Model: |
N601109EE |
MPN: |
N601109EE |
Type: |
Extender Board / PCB Card Module |
SKU: |
26266 |
Condition: |
Used – Inspected and in Good Condition |
Jumpers Installed: |
No Jumpers |
Connector Type: |
Gold-pin multi-pin edge connector |
Form Factor: |
Card / Board Module |
Ejector Handles: |
Yes – black plastic ejector levers |
Seller Notes: |
Board only — no jumpers installed. Inspected and in good condition. |
Country/Region of Manufacture: |
United Kingdom |
Condition Notes: |
Nordiko Limited N601109EE Extender Board inspected and in good condition. PCB clean, no visible damage. No jumpers installed. Gold-pin connectors intact. Black ejector handles present. |
