This is the original Nihon Kohden Operator's Manual for the EEG-4300B series electroencephalographs, publication number OM.EEG4300B.Z06. The manual covers four models — EEG-4314B, EEG-4317B, EEG-4321B, and EEG-4317E — and provides complete operating guidance for these multi-channel clinical EEG machines. The manual dates from 1986, matching the generation of instruments it supports.

Specifications & What's Included

• Manufacturer: Nihon Kohden Corporation
• Publication Number: OM.EEG4300B.Z06
• Document Type: Operator's Manual
• Covers Models: EEG-4314B, EEG-4317B, EEG-4321B, EEG-4317E
• Publication Date: 1986
• Language: English
• Format: Spiral-bound print
• Sections: 10 (Introduction; Preparation for Measurement; EEG Measurement; Additional Operating Instructions; Programming; Common Operating Problems and Maintenance; Controls, Connectors, and Displays Index; Specifications and Standard Accessories; Options; Appendix)
• EEG-4317E supplement included — covers 17-channel configuration differences from EEG-4317B baseline
• EEG-4317E recording pen amplitude: bio-electric signal channels 28mm peak-to-peak max; marker channels 14mm peak-to-peak max (M1/M11)
• EEG-4317E power requirements (per manual): 117VAC, 60Hz, 220VA max
• EEG-4317E unit dimensions (per manual): 1000W × 1035H × 755D mm (40"W × 41"H × 30"D)
• Recording paper spec (per manual): 400mm width × up to 500m length

Applications

Nihon Kohden is a Japanese medical electronics manufacturer that has been a major supplier of clinical neurophysiology equipment since the 1950s. The EEG-4300B series electroencephalographs are multi-channel analog pen-recorder EEG machines designed for clinical neurophysiology departments, hospital neurology units, and EEG laboratories. These instruments were used to record brainwave activity for the diagnosis and monitoring of conditions such as epilepsy, sleep disorders, and other neurological conditions. The EEG-4314B, EEG-4317B, and EEG-4317E models are differentiated primarily by channel count and pen amplitude configuration — the EEG-4317B and EEG-4317E are 17-channel systems. This manual dates from 1986 and is the correct operator reference for servicing departments, biomedical engineering staff, or collectors maintaining these vintage clinical instruments. It covers everything from initial preparation and measurement procedures through programming, troubleshooting, and a full specifications appendix.
