Description
Newport F-MLD-500 Multimode Fiber Spool 100µm Core 140µm Clad 850/1300nm ~495m
Graded-index multimode fiber optic cable on spool. Supports short- to medium-distance data transmission at 850nm and 1300nm wavelengths, typical in legacy and industrial telecommunications systems.
Specifications & What's Included
- Core diameter: 101.2 µm; Cladding: 140 µm; Coating: 250 µm
- Numerical aperture: 0.291
- Operating wavelengths: 850 nm / 1300 nm
- Attenuation: 3.8 dB/km @850nm, 1.4 dB/km @1300nm
- Bandwidth: 100 MHz-km
- Temperature range: -65°C to +135°C
- Buffer: Dual acrylate; Jacket: CSB
- Length: ~495 meters remaining (5m removed)
Applications
Multimode fiber of this specification was used in local area networks, campus networks, and short-range industrial control systems. Compatible with standard multimode transceivers and equipment designed for 850nm short-wavelength systems. Graded-index construction reduces modal dispersion compared to step-index designs.
Condition: New
This Newport F-MLD-500 Multimode Fiber Optic Spool is new old stock from Newport Corporation. The spool is complete and the fiber appears clean and undamaged, but a handwritten note on the label indicates that approximately 5 meters have been removed, leaving roughly 495 meters remaining from the original 500-meter spool. As new old stock, it has not been used in a system, but it may have been stored for an extended period or past any manufacturer-noted shelf date, and it is out of its original sealed packaging. The fiber itself shows no visible damage, kinks, or contamination in the photos. Please review the photos closely and contact us with any questions before purchasing.
This Newport F-MLD-500 Multimode Fiber Optic Spool is new old stock from Newport Corporation. The spool is complete and the fiber appears clean and undamaged, but a handwritten note on the label indicates that approximately 5 meters have been removed, leaving roughly 495 meters remaining from the original 500-meter spool. As new old stock, it has not been used in a system, but it may have been stored for an extended period or past any manufacturer-noted shelf date, and it is out of its original sealed packaging. The fiber itself shows no visible damage, kinks, or contamination in the photos. Please review the photos closely and contact us with any questions before purchasing.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Newport |
Model: |
F-MLD-500 |
MPN: |
F-MLD-500 |
Type: |
Graded-Index Multimode Fiber Optic Cable Spool |
SKU: |
52312 |
Fiber Type: |
Graded-Index Multimode |
Core Diameter: |
101.2 µm |
Cladding Diameter: |
140 µm |
Coating Diameter: |
250 µm ±15 µm |
Buffer Coating Material: |
Dual Acrylate |
Jacket Type: |
CSB |
Numerical Aperture (NA): |
0.291 |
Maximum Attenuation: |
3.8 dB/km @850nm / 1.4 dB/km @1300nm |
Bandwidth: |
100 MHz-km @850nm / @1300nm |
Proof Test: |
100 kpsi |
Original Spool Length: |
500 meters |
Approximate Remaining Length: |
~495 meters (5m removed) |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Note on spool indicates approximately 5 meters removed; ~495m remaining. |
Condition: |
New – Old Stock (open spool, 5m removed) |
Condition Notes: |
Newport F-MLD-500 Multimode Fiber Spool — new old stock. ~495m remaining (5m removed per label note). Fiber appears clean and undamaged. May have been stored long-term or past shelf date. Out of original packaging. |
