Description
Motorola MC68A50P ACIA Asynchronous Communications Interface Adapter 24-Pin DIP
The MC68A50P is a serial communications interface IC designed for Motorola 6800-series microprocessor systems. It provides asynchronous, full-duplex serial communication (UART functionality) at 1.5 MHz clock frequency.
Specifications & What's Included
- Type: Asynchronous Communications Interface Adapter (ACIA)
- Package: 24-Pin DIP (Dual Inline Package)
- Clock Frequency: 1.5 MHz
- Supply Voltage: 5V DC
- Logic Family: NMOS, 6800-series compatible
- Interface: Serial (UART-style, full-duplex)
- Date Code: T6A8406 (week 06, 1984)
- Manufactured in Korea
- Single IC chip only
Applications
The MC68A50P was used in retro computing systems built around Motorola 6800, 6802, and 6809 microprocessors, including industrial controllers, early computer systems, and telecom equipment. This adapter handled serial data transmission between the MPU and peripherals such as modems, terminals, and other serial devices. It remains relevant for restoration and maintenance of vintage 6800-based hardware.
Condition: Used
This Motorola MC68A50P ACIA 24-pin DIP IC has been inspected and is in good used condition. It was pulled from a working environment where it was previously in use. The chip body is intact with no cracks or damage, and all 24 pins appear straight and undamaged. Date code T6A8406 is visible on the chip. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
This Motorola MC68A50P ACIA 24-pin DIP IC has been inspected and is in good used condition. It was pulled from a working environment where it was previously in use. The chip body is intact with no cracks or damage, and all 24 pins appear straight and undamaged. Date code T6A8406 is visible on the chip. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Motorola |
Model: |
MC68A50P |
MPN: |
MC68A50P |
Type: |
Asynchronous Communications Interface Adapter (ACIA) IC |
SKU: |
27860 |
Package / Case: |
24-Pin DIP (Dual Inline Package) |
Clock Frequency: |
1.5 MHz |
Number of Pins: |
24 |
Interface: |
Serial (UART-style, full-duplex) |
Logic Family: |
NMOS / 6800-series compatible |
Supply Voltage: |
5V DC |
Compatible With: |
Motorola 6800, 6802, 6809 MPU systems |
Date Code: |
T6A8406 (visible on chip label — week 06, 1984) |
Country/Region of Manufacture: |
Korea (visible on chip in Image 3) |
Condition: |
Used – Pulled from Working Environment |
Seller Notes: |
Single IC chip only. Pulled from working environment, inspected. |
Condition Notes: |
Motorola MC68A50P ACIA 24-pin DIP IC pulled from a working environment and inspected. Chip body intact, all 24 pins appear straight and undamaged. Date code T6A8406 visible. Good used condition. |
California Prop 65 Warning: |
WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov |
