McPherson 815 Pumping Control System For Parts Broken Gauge Vacuum Lab
The McPherson 815 is a benchtop pumping control system designed to monitor and control vacuum pump operations in scientific and laboratory environments. The front panel features three large analog panel meters — labeled across the left, center, and right positions — along with an extensive array of push-button controls and two rotary knobs providing multi-function system operation. The rear panel is densely populated with multi-pin circular connectors and terminal connections for interfacing with pumps and peripheral equipment.
Specifications & What's Included
- Make: McPherson
- Model: 815
- Type: Pumping Control System
- Front panel: three analog panel meters (left, center, right gauge positions)
- Center gauge glass: broken (clearly visible in photos)
- Controls: multi-function push-button array across lower panel face, two rotary control knobs
- Rear panel: multiple multi-pin circular connectors and terminal blocks for pump and system interfacing
- Form factor: benchtop / rack-panel instrument chassis
- Sold AS-IS, for parts or repair — no accessories confirmed included
Applications
McPherson is a Massachusetts-based scientific instruments company best known for spectrometers and vacuum ultraviolet (VUV) optical instruments. The Model 815 Pumping Control System was used in laboratory vacuum system setups — typically to automate and monitor the sequential operation of roughing pumps, turbomolecular pumps, or diffusion pumps used to evacuate optical instrument chambers and vacuum deposition systems. These controllers were common on McPherson spectrometer systems and related optical bench setups from the 1970s and 1980s, where maintaining and monitoring vacuum levels was critical to instrument performance. Buyers today are typically researchers, universities, or labs maintaining legacy McPherson optical instruments and spectrometers, or those seeking parts for similar vintage vacuum control panels.
This McPherson 815 Pumping Control System is being sold AS-IS for parts or repair. The glass on the center panel gauge is broken, as clearly visible in the photos. The unit has not been tested and no functionality is guaranteed. It may be suitable for parts harvesting or restoration. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
McPherson |
Model: |
815 |
MPN: |
815 |
Type: |
Pumping Control System |
SKU: |
11928 |
Condition: |
As-Is / For Parts or Not Working |
Seller Notes: |
Sold AS-IS. Center gauge glass is broken. No functionality guarantee. |
Form Factor: |
Benchtop / Rackmount Panel |
Number of Gauges: |
3 (analog panel meters) |
Panel Controls: |
Multi-function push-button array, two rotary knobs |
Application: |
Vacuum pumping system control and monitoring |
Country/Region of Manufacture: |
United States |
Condition Notes: |
McPherson 815 Pumping Control System sold AS-IS for parts or repair. Center gauge glass is broken. Unit has not been tested; no functionality guaranteed. See photos for details. |
