Description
King Instrument 7511315B03 Acrylic Rotameter Air Flow Meter 0-8 SCFM
The King Instrument Company 7511315B03 is a variable area flow meter (rotameter) designed to measure air flow at standard temperature and pressure (STP). The clear acrylic tube allows direct visual reading of the ball float position, with a printed scale graduated from 0 to 8 SCFM. The label on the body specifies readings in SCFM for air at STP, and instructs the user to read the float at its largest diameter. Both ends are fitted with stainless steel 90° elbow fittings for inline installation.
Specifications & What's Included
- Part Number: 7511315B03
- Manufacturer: King Instrument Company
- Type: Variable Area Flow Meter (Rotameter)
- Tube Material: Clear acrylic
- Measured Media: Air
- Flow Range: 0–8 SCFM
- Measurement Standard: STP (Standard Temperature and Pressure)
- Float: Ball float — read at largest diameter
- Fittings: Two stainless steel 90° elbow fittings (one each end), included and installed
- Overall Length: Approximately 11–12 inches (measured in photos)
- Scale printed on tube:Condition: Used
This King Instrument Company 7511315B03 acrylic rotameter (air flow meter) has been inspected and appears to be in good used condition. The clear acrylic tube is intact with no visible cracks or chips, and both stainless steel 90° elbow fittings are present and show normal handling wear. The float and scale markings are clean and legible. It was pulled from a working environment where it was previously in use. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
King Instrument Company |
Model: |
7511315B03 |
MPN: |
7511315B03 |
Type: |
Variable Area Flow Meter (Rotameter) |
SKU: |
46962 |
Flow Range: |
0–8 SCFM |
Media: |
Air |
Flow Measurement Standard: |
STP (Standard Temperature and Pressure) |
Tube Material: |
Acrylic (Clear) |
Float Type: |
Ball float — read at largest diameter |
Fitting Type: |
90° Elbow Fittings (Stainless Steel) |
Seller Notes: |
Includes two stainless steel 90° elbow fittings installed on each end |
Country/Region of Manufacture: |
United States |
Form Factor: |
Inline / Panel Mount |
Compatible With: |
Compressed air systems, pneumatic lines, industrial gas flow monitoring |
Condition Notes: |
This King Instrument 7511315B03 acrylic air rotameter has been inspected and is in good used condition. Acrylic tube is intact, fittings present, float and scale legible. Pulled from a working environment. |
