Lexel
Was:
$550.00
Was:
$1,100.00
Lexel 95-5 Ion Laser 109-001-L2 w/Model 295 Power Supply 8W CW Argon For PartsLexel 95-5 Argon Ion laser head with matching Model 295 power supply. 8-watt CW output at 208 VAC, 3-phase, 45A...
39732
- SKU:
- 39732
- Availability:
- Usually ships within 1-2 business days.
- Weight:
- 204.00 LBS
- Brand:
- Lexel Laser
- Model:
- 95-5
- MPN:
- 109-001-L2
- Secondary Model:
- Model 295 Power Supply
- Secondary MPN:
- 112-002-07
- Tube Model:
- 5085Ar
- Tube Part Number:
- 0300-4040 Q-2
- SKU:
- 39732
- Type:
- Argon Ion Laser
- Laser Type:
- Argon Ion (Ar+)
- Laser Class:
- Class IV
- Output Power:
- 8 Watts CW Argon
- Power Requirements:
- 208 VAC, 3-Phase, 45A, 50/60 Hz
- Voltage:
- 208 VAC
- Phase:
- Three Phase
- Current Rating:
- 45 Amperes
- Frequency:
- 50/60 Hz
- Manufacture Date:
- June 1988
- Serial Number (Laser Head):
- 95-170 H
- Country/Region of Manufacture:
- United States
- Manufacturer Location:
- Fremont, California
- Form Factor:
- Benchtop / External Power Supply
- Condition:
- As-Is / For Parts or Not Working
- Seller Notes:
- Includes laser head (109-001-L2) and Model 295 power supply (112-002-07). Blows fuse on power-up; sold AS-IS for parts.
- Beam Attenuator:
- Yes — Closed/Open attenuator on output end
- Emission Indicator:
- Yes — Laser Radiation Emission Indicator on front panel
- Wavelength Adjustment:
- Yes — Vertical & Wavelength / Horizontal tuning knobs
- Hour Meter:
- Curtis 420-LNA, 275 VDC, 0–5000 Hours
- Cooling:
- Water-cooled (water fittings and hose included)
- Compatible With:
- Lexel Model 295 Ion Laser Power Supply
- Application:
- Spectroscopy, holography, flow cytometry, pumping dye lasers
- Certification:
- Conforms to 21 CFR Chapter 1, Subchapter J (Radiation Control for Health and Safety Act of 1968)
- Condition Notes:
- Lexel 95-5 Argon Ion Laser w/ Model 295 PSU sold AS-IS for parts. Blows fuse on power-up; untested beyond that. Fault not diagnosed. May have many usable components. Please view photos and contact us with questions.
- California Prop 65 Warning:
- WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov
