Description
Intel Pentium A80502166 SY016 166MHz Socket 5/7 CPU Processor P54C
Single-core x86 processor from Intel's Pentium line, operating at 166 MHz. This CPU was designed for Socket 5 and Socket 7 compatible motherboards and supported dual-voltage operation.
Specifications & What's Included
- Model: A80502166 (SY016)
- Clock Speed: 166 MHz / Bus Speed: 66 MHz
- Socket Type: Socket 5 / Socket 7
- Architecture: Intel Pentium P54C, 350nm process
- Cache: 16 KB L1 (8 KB instruction + 8 KB data)
- Voltage: 3.3V (VRE) dual-voltage
- Form Factor: CPGA ceramic package
- Processor only — no heatsink or fan included
Applications
This processor was used in personal computers and workstations from the mid-1990s. Compatible with Intel 430VX, 430TX, and equivalent chipset motherboards. Commonly found in systems used for general computing, light multimedia work, and office applications during that era. The Socket 5/7 dual-socket compatibility provided flexibility in platform selection.
Condition: Used
This Intel Pentium A80502166 SY016 166MHz Socket 5/7 processor has been inspected and appears to be in good used condition. It was pulled from a working environment. The ceramic package shows light surface scuffing and typical handling wear consistent with its age, visible on the top face. The gold pins on the underside are intact with no visible bending or damage. Processor only — no heatsink or fan is included. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
This Intel Pentium A80502166 SY016 166MHz Socket 5/7 processor has been inspected and appears to be in good used condition. It was pulled from a working environment. The ceramic package shows light surface scuffing and typical handling wear consistent with its age, visible on the top face. The gold pins on the underside are intact with no visible bending or damage. Processor only — no heatsink or fan is included. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Intel |
Model: |
A80502166 |
MPN: |
SY016 |
Secondary Model: |
SY016/VSS |
Type: |
CPU / Processor |
Processor Model: |
Pentium 166MHz |
Processor Family: |
Intel Pentium P54C |
Clock Speed: |
166 MHz |
Socket Type: |
Socket 5 / Socket 7 |
Number of Cores: |
1 |
Bus Speed: |
66 MHz |
Voltage: |
3.3V (VRE) / dual-voltage |
Process Technology: |
350nm (0.35 micron) |
L1 Cache: |
16 KB (8 KB instruction + 8 KB data) |
Compatible With: |
Socket 5 and Socket 7 motherboards |
Country/Region of Manufacture: |
Malaysia |
Form Factor: |
CPGA (Ceramic Pin Grid Array) |
Condition: |
Used – Pulled from Working Environment |
SKU: |
12070 |
Seller Notes: |
Processor only; no heatsink or fan included. |
Condition Notes: |
Intel Pentium A80502166 SY016 166MHz CPU pulled from a working environment. Inspected and in good used condition. Ceramic package shows light surface wear; gold pins intact. Processor only — no heatsink or fan included. |
