Intel Pentium 200MHz MMX Processor BP80502200 SU114 Socket 7 CPU
The Intel Pentium 200MHz MMX (BP80502200) is a Socket 7 processor running at 200MHz on a 66MHz front-side bus. It carries the SU114/VSS stepping and an ICOMP 2 rating of 142. The MMX instruction set, introduced with this processor generation, added 57 new SIMD instructions targeted at multimedia and signal-processing workloads — a significant update to the original P5 Pentium architecture.
Specifications & What's Included
- Manufacturer: Intel
- Part Number: BP80502200
- Stepping / S-Spec: SU114/VSS
- Clock Speed: 200 MHz
- Front-Side Bus: 66 MHz
- Socket: Socket 7 (ceramic PGA)
- Instruction Set: x86 + MMX
- ICOMP 2 Rating: 142
- L1 Cache: 32 KB (16 KB instruction + 16 KB data)
- Voltage: 2.8V core (VRE standard for MMX Pentium)
- Process: 0.35 micron CMOS
- Package: 296-pin ceramic PGA
- Date codes on label: C6480565-0288, ©92/93
- Processor only — no heatsink or fan included
Applications
The Pentium MMX 200 was Intel's top-of-the-line Socket 7 desktop processor when it launched in early 1997, and it remains the fastest standard-voltage chip the Socket 7 platform officially supports. It is still actively sought for restoring and upgrading mid-1990s Socket 7 systems — particularly boards built around the Intel 430HX, 430VX, 430TX, and compatible VIA/SiS chipsets. Collectors and vintage PC enthusiasts use it to bring period-correct machines to their maximum stock performance. It also fits a range of Socket 7 industrial single-board computers and embedded platforms from the same era that accept MMX-grade processors. Because the MMX Pentium requires split voltage (3.3V I/O, 2.8V core), the host board must have a voltage regulator module (VRM) or built-in voltage regulation supporting the MMX specification — a point worth confirming before installation.
This Intel Pentium 200MHz MMX Processor (BP80502200, SU114/VSS stepping) has been tested at our facility and is in good working condition. The gold PGA pins are clean and straight with no visible bending or corrosion. The ceramic package shows light handling wear typical of a pulled processor. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Intel |
Model: |
BP80502200 |
MPN: |
BP80502200 |
Secondary Model: |
SU114 |
SKU: |
41513 |
Type: |
CPU / Processor |
Processor Model: |
Pentium MMX 200MHz |
Clock Speed: |
200 MHz |
Socket Type: |
Socket 7 |
Processor Family: |
Intel Pentium MMX |
Stepping: |
SU114/VSS |
ICOMP Rating: |
ICOMP 2 #=142 |
Bus Speed: |
66 MHz |
Instruction Set: |
x86, MMX |
Country/Region of Manufacture: |
Malaysia |
Form Factor: |
OPGAa (Ceramic PGA) |
Compatible With: |
Socket 7 motherboards supporting Pentium MMX |
Seller Notes: |
Processor only. No heatsink or fan included. |
Condition Notes: |
This Intel Pentium 200MHz MMX Processor BP80502200 (SU114/VSS) has been tested and is in good working condition. Pins are clean and straight. Light handling wear on the ceramic package. Please contact us with any questions. |
