Description
IBM 4869 72X6759 360KB 5.25" External Floppy Drive PS/2 RS449 37-Pin
The IBM 4869 is a proprietary external 5.25-inch double-density floppy disk drive designed exclusively for the IBM PS/2 line of personal computers. It connects to the host system via a parallel RS449 interface using a 37-pin D-sub connector rather than the standard internal floppy ribbon cable — making it a dedicated external peripheral that requires a specific IBM Diskette Adapter Card to operate. The drive and its RS449 cable are included; the adapter card is not.
Specifications & What's Included
- Manufacturer: IBM (International Business Machines Corporation, Armonk, NY)
- Model / Type: 4869
- FRU Part Number: 72X6759
- Secondary Part Number: 86-0262169
- Disk Format: 5.25-inch double-density (DD), 360KB
- Interface: Parallel RS449, 37-pin D-sub connector
- Power Input: 100–125V AC, 0.8A / 200–240V AC, 0.4A, 50/60Hz
- Form Factor: External desktop enclosure
- Country of Manufacture: Japan
- FCC ID: ANO9Z64869
- Certifications: UL Listed (EDP Equip. 64T5), CSA
- Included: IBM 4869 external floppy drive unit + RS449 37-pin interface cable
- Not Included: IBM Diskette Adapter Card (required — compatible example: FRU 15F7996)
Applications
The IBM PS/2 line, introduced in 1987, moved away from the earlier PC/XT/AT architecture and used a proprietary Micro Channel Architecture (MCA) bus. IBM's external storage peripherals for the PS/2 used a parallel RS449 interface — a non-standard approach that required a dedicated IBM Diskette Adapter Card installed inside the PS/2 host. The 4869 was used to add a second 5.25-inch 360KB floppy drive externally, which was important during the transition era when 5.25-inch media was still common and the PS/2's internal bays used 3.5-inch drives. Today these drives are sought by collectors and by organizations maintaining legacy PS/2 systems that need to read or archive 5.25-inch diskette media. Compatible IBM PS/2 systems include the Model 50, 60, 70, 80, and related machines equipped with an appropriate diskette adapter card.
This IBM 4869 External 5.25" Floppy Drive has been tested and is in good working condition. The unit shows normal cosmetic wear consistent with its age, including light yellowing of the beige plastic housing — typical for equipment of this era. The drive bay doors and red power switch are intact. The RS449 37-pin interface cable is included. Note that this drive requires an IBM Diskette Adapter Card (such as FRU 15F7996) to connect to an IBM PS/2 host — that adapter card is NOT included. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
IBM |
Model: |
4869 |
MPN: |
72X6759 |
Secondary Model: |
86-0262169 |
SKU: |
43260 |
Type: |
External Floppy Disk Drive |
Disk/Media Format: |
5.25" DD 360KB |
Interface: |
RS449 (37-pin D-sub) |
Compatible With: |
IBM PS/2 computers |
Required Adapter: |
IBM Diskette Adapter Card FRU 15F7996 |
Power Input: |
100-125V 0.8A / 200-240V 0.4A, 50/60Hz |
Form Factor: |
External Desktop |
Country/Region of Manufacture: |
Japan |
FCC ID: |
ANO9Z64869 |
Seller Notes: |
Includes RS449 37-pin cable. Requires IBM Diskette Adapter Card FRU 15F7996 (not included). |
Condition Notes: |
This IBM 4869 External 5.25" Floppy Drive has been tested and is in good working condition. Shows light cosmetic yellowing typical for its age. RS449 37-pin cable included. IBM Diskette Adapter Card (FRU 15F7996) required but not included. |
