Description
IBM 02K6661 AC Adapter 16V 4.5A 72W Barrel Plug ThinkPad Laptop Power Supply
The IBM 02K6661 is an OEM AC power adapter designed to power IBM ThinkPad laptops. It converts standard AC mains power to a regulated 16V DC output at up to 4.5A (72W), delivered via a barrel-style DC output connector. The adapter accepts a wide-range AC input (100–240V), making it compatible with both North American and international mains voltages.
Specifications & What's Included
- Manufacturer Part Number: 02K6661
- Output Voltage: 16V DC
- Output Current: 4.5A
- Output Power: 72W
- Input Voltage: 100–240V AC, 50/60Hz
- Input Current: 1.6A (100V) – 0.8A (240V)
- DC Output Connector: Barrel plug
- AC Input Connector: IEC C7 (figure-8 / two-pin)
- Form Factor: External power brick with integrated cable wrap and velcro strap
- Certifications: UL, cUL, CE, V85
- Includes: AC adapter with barrel plug DC output cable and AC input cord
Applications
The IBM 02K6661 is a ThinkPad-era AC adapter produced during the period when IBM still manufactured its own laptop line, before the ThinkPad brand was sold to Lenovo in 2005. Adapters in this family were standard power supplies for a range of IBM ThinkPad models from the late 1990s through the mid-2000s — including the ThinkPad T, R, and A series — and are still sought by users maintaining or restoring those machines. The wide-range AC input makes this adapter usable worldwide with an appropriate plug adapter. It is also commonly used as a bench power source in lab and repair settings where a clean 16V regulated supply is needed.
This IBM 02K6661 AC adapter (16V DC, 4.5A) has been inspected and appears to be in good used condition. The housing shows normal wear consistent with prior use, and the IBM logo and label markings are intact and legible. The barrel plug output connector and AC input port appear undamaged. It has not been powered up or tested at our facility, but comes from a previously operational environment. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
IBM |
Model: |
02K6661 |
MPN: |
02K6661 |
Type: |
AC Adapter / Laptop Power Supply |
SKU: |
26047 |
Output Voltage: |
16V DC |
Output Current: |
4.5A |
Output Power: |
72W |
Input Voltage: |
100-240V AC, 50/60Hz |
Input Current: |
1.6A - 0.8A |
Connector Type: |
Barrel Plug |
Compatible With: |
IBM ThinkPad Laptops |
Form Factor: |
External Brick |
Cord Included: |
Yes — AC input cord included |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Includes AC adapter with attached barrel plug output cable and AC input cord. |
Condition Notes: |
This IBM 02K6661 AC adapter (16V 4.5A) has been inspected and is in good used condition with normal wear. Not powered up or tested at our facility; pulled from a working environment. Please contact us with any questions. |
