Huntington Electric FSE-1000 HE11005 10 Ohm 5P Wirewound Resistor w/ Holder

Huntington Electric FSE-1000 HE11005 10 Ohm 5P Wirewound Resistor w/ Holder

The Huntington Electric FSE-1000 is a tubular wirewound power resistor rated at 10 ohms with a 5% tolerance, identified by part number HE11005. It is mounted in a steel chassis holder with bracket feet for secure panel or chassis mounting. The markings on the resistor body — HE11005, FSE-1000, 10 OHM 5P — are clearly printed and fully legible. This unit has been tested and is in working order.

Specifications & What's Included

• Manufacturer: Huntington Electric
• Model: FSE-1000
• Part Number: HE11005
• Resistance: 10 Ohm
• Tolerance: 5% (5P)
• Construction: Tubular wirewound element with textured outer jacket
• Mounting: Steel chassis holder with two L-bracket feet for panel/chassis attachment
• Terminals: Axial stud/post terminals at each end cap
• Includes: Resistor and steel mounting holder/bracket assembly as shown

Applications

Tubular wirewound power resistors like the FSE-1000 are used in a wide range of industrial, power electronics, and test equipment applications where precise, stable resistance values and the ability to dissipate significant heat are required. Common uses include load banks, braking resistors in motor drive circuits, voltage dividers, current-limiting circuits, and dummy loads in power supply or amplifier testing. The chassis-mount holder allows the resistor to be bolted directly to a metal panel or enclosure frame, which also aids in heat dissipation. Huntington Electric has long produced wirewound resistors for industrial and OEM applications in the United States. This style of tubular ceramic-core wirewound resistor has been a standard component in industrial control panels, power conversion equipment, and laboratory test setups for decades and remains in widespread use today.
