HP 54501A 5954-2673 Digitizing Oscilloscope Front Panel Operation Reference 1988
This is the original Hewlett-Packard Front Panel Operation Reference for the HP 54501A Digitizing Oscilloscope, publication number 5954-2673, printed April 1988. It is a ring-bound binder covering the complete front-panel interface of the 54501A — from initial layout and setup through automatic and manual measurements, waveform storage, hardcopy output via HP-IB, and dual timebase windowing. Note: the spine label identifies this as the Front Panel Operation Reference, which is an operator-focused companion guide rather than the full service manual.
Specifications & What's Included
- Publication Number: 5954-2673
- Print Date: April 1988
- Instrument: HP 54501A Digitizing Oscilloscope
- Document Type: Front Panel Operation Reference
- Format: Ring binder
- Language: English
- Coverage: Chapters 1–8, including layout and setup, front panel overview, instant setup, automatic and manual measurements, waveform storage, HP-IB hardcopy output, and dual timebase windowing
- Publisher: Hewlett-Packard
Applications
The HP 54501A is a four-channel, 20 MHz digitizing oscilloscope from Hewlett-Packard's 54500 Series, introduced in the late 1980s. The 54500 Series represented HP's entry into digitizing oscilloscopes at the time — instruments that sampled and stored waveforms digitally rather than simply displaying them in real time, enabling measurements like automatic voltage, time interval, and waveform period calculations that analog scopes could not perform without external equipment. The HP-IB (IEEE-488) interface built into the 54501A allowed it to integrate into automated test systems and produce hardcopy output through compatible printers and plotters, which was a standard capability in HP test equipment of that era. This Front Panel Operation Reference covers the operator-facing controls and measurement procedures, making it the go-to reference for anyone setting up, operating, or learning the 54501A's measurement capabilities. It remains a practical resource for engineers and technicians maintaining or using a 54501A today, as well as for collectors of HP vintage test equipment.
This HP 54501A Digitizing Oscilloscope Front Panel Operation Reference (publication 5954-2673, April 1988) is in good used condition. The binder shows some wear at the lower spine corner, and there is a handwritten 'ASE' marking on the front cover. The pages are clean, intact, and fully legible throughout. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Hewlett-Packard |
Model: |
54501A |
MPN: |
5954-2673 |
Type: |
Oscilloscope Front Panel Operation Reference Manual |
SKU: |
49057 |
Document Type: |
Front Panel Operation Reference |
Publication Number: |
5954-2673 |
Print Date: |
April 1988 |
For Make/Model: |
HP 54501A Digitizing Oscilloscope |
Language: |
English |
Format: |
Ring Binder |
Compatible With: |
HP 54501A Digitizing Oscilloscope |
Series: |
HP 54500 Series |
Condition: |
Used – Inspected and in Good Condition |
Seller Notes: |
Original HP ring binder; all pages present and legible; handwritten 'ASE' marking on cover |
Country/Region of Manufacture: |
United States |
Condition Notes: |
This HP 54501A Digitizing Oscilloscope Front Panel Operation Reference (pub 5954-2673, April 1988) is in good used condition. Binder shows wear at lower spine corner; handwritten 'ASE' marking on cover. Pages are clean, intact, and legible. |
