HP 16510A 5959-6075 Logic Analyzer Module Front-Panel Operation Reference 1989

HP 16510A 5959-6075 Logic Analyzer Module Front-Panel Operation Reference 1989

This is the original Hewlett-Packard front-panel operation reference for the HP 16510A Logic Analyzer Module, publication number 5959-6075, printed January 1989. It is a complete ring-bound manual providing step-by-step guidance for operating the 16510A module directly from its front panel, covering the timing analyzer, state analyzer, and timing/state combination modes.

Specifications & What's Included

• Title: HP 16510A Logic Analyzer Module Front-Panel Operation Reference
• HP Part Number / Publication Number: 5959-6075
• Print Date: January 1989
• For Instrument: HP 16510A Logic Analyzer Module
• Format: Ring binder with tabbed chapter dividers
• Language: English
• Chapters covered include: Basic Logic Analyzer Menu, Using the Timing Analyzer, Using the State Analyzer, Using the Timing/State Analyzer (Chapters 4–7 and additional sections visible in table of contents)
• Binder spine label intact; HP logo and title clearly printed

Applications

The HP 16510A is a logic analyzer module designed for use in HP's modular logic analysis mainframes of the late 1980s — a period when HP dominated the logic analysis market with configurable card-based systems. Logic analyzer modules of this type were central tools in digital hardware design, embedded systems development, and microprocessor debugging, allowing engineers to capture and display multiple logic signals simultaneously in both timing (waveform) and state (data bus) modes. This front-panel operation reference is specifically written for bench use, walking the operator through setup, probe connection, trigger condition configuration, data acquisition, and result display without requiring a host computer. Engineers maintaining or repairing legacy HP logic analysis systems, as well as collectors of HP test equipment documentation, will find this a practical and period-accurate reference for the 16510A module.
