Description
Goorui GHBH 004 34 AR7 Ring Blower 3-Phase 3kW 135CFM 22kPa 200-240V Side Channel
A three-phase side channel ring blower designed for industrial air movement and pneumatic conveying applications. This regenerative blower generates pressure and airflow for material handling systems, vacuum packaging equipment, and pneumatic transport lines.
Specifications & What's Included
- Model: GHBH 004 34 AR7 | Serial: GOORUI131226-00434AR7-006
- Power: 3.0 kW (50Hz) / 3.45 kW (60Hz)
- Voltage: 200-240V / Y345-415V AC (50Hz); 220-275V / Y380-480V AC (60Hz)
- Airflow: 135 CFM rated; max 247 CFM (50Hz) / 293 CFM (60Hz)
- Pressure: 22 kPa (50Hz) / 19 kPa (60Hz)
- IP54 enclosure, Class F insulation, 70 dB noise level
- Dimensions: 16 in × 16 in × 14.5 in | Floor-mount standalone unit
Applications
Side channel blowers are used in industrial pneumatic conveying, material transfer systems, and vacuum packaging operations. Common applications include grain handling, powder transport, wastewater aeration, and compressed air backup systems in production environments.
Condition: Used
This Goorui GHBH 004 34 AR7 side-channel ring blower is in very clean used condition. The gold cast-aluminum housing and cooling fins show minimal wear consistent with careful prior use or storage, and the unit presents well cosmetically throughout. The rating plate is fully legible with all specs intact. Due to its size and weight (approximately 43 kg / 95 lbs), this blower requires special freight shipping — please contact us before purchasing to obtain a shipping quote or to arrange local pickup or an in-person viewing at our facility. Please view our photo set and contact us if you have any questions.
This Goorui GHBH 004 34 AR7 side-channel ring blower is in very clean used condition. The gold cast-aluminum housing and cooling fins show minimal wear consistent with careful prior use or storage, and the unit presents well cosmetically throughout. The rating plate is fully legible with all specs intact. Due to its size and weight (approximately 43 kg / 95 lbs), this blower requires special freight shipping — please contact us before purchasing to obtain a shipping quote or to arrange local pickup or an in-person viewing at our facility. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Goorui |
Model: |
GHBH 004 34 AR7 |
MPN: |
GHBH 004 34 AR7 |
Serial Number / Label: |
GOORUI131226-00434AR7-006 |
Type: |
Side Channel Ring Blower / Regenerative Blower |
SKU: |
51688 |
Country/Region of Manufacture: |
China |
Phase: |
Three Phase |
Number of Poles: |
2 Pole |
Power Rating (50Hz): |
3.0 kW |
Power Rating (60Hz): |
3.45 kW |
Voltage (50Hz): |
200-240V / Y345-415V AC |
Voltage (60Hz): |
220-275V / Y380-480V AC |
Current (50Hz): |
12.5 / 7.2 Amp |
Current (60Hz): |
12.5 / 7.3 Amp |
Frequency: |
50 Hz / 60 Hz |
Max Air Flow (50Hz): |
7 m³/min (approx. 247 CFM) |
Max Air Flow (60Hz): |
8.3 m³/min (approx. 293 CFM) |
Rated Pressure (50Hz): |
22 kPa |
Rated Pressure (60Hz): |
19 kPa |
Airflow (CFM): |
135 CFM (rated operating point) |
Insulation Class: |
Class F |
Enclosure Rating: |
IP54 |
Noise Level: |
70 dB |
Dimensions: |
16 in x 16 in x 14.5 in |
Form Factor: |
Standalone / Floor Mount |
Manufacturer Group: |
HKFLS Group |
Seller Notes: |
Unit only. Requires special freight shipping — contact seller for quote. |
Condition: |
Used – Inspected, Very Clean |
Condition Notes: |
Goorui GHBH 004 34 AR7 ring blower in very clean used condition. Housing and fins show minimal wear. Rating plate fully legible. Requires special freight shipping — contact us for a quote before purchasing. |
