Description
Furnas 40FF32AAD6 3-Pole Lighting Contactor 60A 600VAC Coil 75D73070A 110-240V
The Furnas 40FF32AAD6 is a 3-pole, 60-amp electromagnetic lighting contactor designed for switching high-wattage lighting loads including tungsten filament and ballast-type fixtures. It operates via a magnetic coil that energizes and de-energizes the main contacts, allowing remote or automated control of large lighting circuits from a low-voltage control signal. The unit includes the 75D73070A magnetic coil rated for 110–240V AC operation at 50/60Hz.
Specifications & What's Included
- Model / Cat. No.: 40FF32AAD6
- Number of Poles: 3
- Current Rating: 60A max
- Ballast Load Rating: 600VAC max
- Tungsten Filament Load Rating: 480VAC max
- DC Tungsten Filament: 3 poles in series, 250V max
- Included Magnetic Coil: 75D73070A
- Coil Voltage: 110–240V AC, 50/60Hz
- Main Terminal Type: Lug-style top and bottom terminals
- Certifications: UL Listed (IND CONT EQ A163), CSA
- Manufacturer: Furnas Electric Co., Batavia, IL
Applications
Lighting contactors like the Furnas 40FF32AAD6 are used throughout commercial and industrial facilities to remotely switch large banks of lighting loads — including fluorescent, tungsten filament, and HID/ballast fixtures — from a centralized control panel or building automation system. This type of contactor is commonly found in warehouses, manufacturing facilities, gymnasiums, parking garages, and outdoor area lighting systems where individual circuit breakers are insufficient for automated control. Furnas (now part of Siemens) produced this series for decades and these contactors remain widely used in legacy panel retrofits and replacement applications.
Furnas 40FF32AAD6 3-Pole Lighting Contactor 60 Amp 110–250V 600 VAC is offered in good used condition, having been pulled from active service in a working industrial environment. The green housing exhibits typical surface wear and minor scuffing consistent with field use. The lug terminals and coil lead wires remain intact and functional. Please refer to the detailed photo set for a complete visual assessment, and contact us with any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
Furnas |
Model: |
40FF32AAD6 |
MPN: |
40FF32AAD6 |
Type: |
Lighting Contactor |
SKU: |
31727 |
Number of Poles: |
3 |
Current Rating (Amps): |
60A |
Voltage Rating: |
600VAC Max |
Tungsten Filament Rating: |
480VAC Max |
Ballast Rating: |
600VAC Max |
Coil Part Number: |
75D73070A |
Coil Voltage: |
110–240V AC, 50/60Hz |
Load Type: |
Tungsten Filament, Ballast |
Certifications: |
UL Listed, CSA |
Listing Code: |
IND CONT EQ A163 |
Manufacturer Location: |
Batavia, IL |
Country/Region of Manufacture: |
United States |
Condition: |
Used – Pulled from Working Environment |
Seller Notes: |
Includes installed 75D73070A magnetic coil rated 110–240V 50/60Hz |
Condition Notes: |
Good used condition, pulled from active service. Green housing shows typical wear & minor scuffing. Lug terminals & coil leads intact. See photos. |
