Description
ESM Cable Corp RG-142 Coaxial Cable 10in N-Male to N-Female N-M N-F 50 Ohm
This is a 10-inch RG-142 coaxial cable assembly from ESM Cable Corp, configured with an N-Male connector on one end and an N-Female connector on the other. RG-142 is a double-shielded, silver-plated copper conductor coaxial cable with a PTFE (Teflon) dielectric, known for its flexibility, low loss at microwave frequencies, and ability to handle elevated temperatures. The 50 Ohm impedance is standard for RF and microwave signal work. Part number Z01037-005RB is printed on the label affixed to the cable jacket.
Specifications & What's Included
- Manufacturer: ESM Cable Corp
- Cable Type: RG-142 (double-shielded, PTFE dielectric, silver-plated conductors)
- Part Number: Z01037-005RB
- Length: 10 inches (approximately 25 cm)
- Impedance: 50 Ohm
- Connector End 1: N-Female (N-F)
- Connector End 2: N-Male (N-M)
- Connector material: Nickel-plated stainless/brass with machined coupling nut
- Includes: Cable assembly only
Applications
RG-142 cable assemblies with N-type connectors are widely used in RF and microwave test and measurement setups, signal routing in laboratory bench configurations, antenna feed connections, and telecommunications equipment. N-type connectors are a rugged, weatherproof connector standard rated to 18 GHz and above, common in cellular infrastructure, two-way radio, satellite ground equipment, and instrumentation. The N-Male to N-Female configuration makes this cable useful as a short extension or adapter jumper between instruments, antenna systems, or panel-mounted ports. RG-142 specifically is favored where both flexibility and performance above 1 GHz are needed, and its PTFE construction makes it suitable for elevated-temperature environments such as those found in avionics, defense electronics, and RF power amplifier testing. Short assemblies like this 10-inch length are typically used for internal rack routing or bench interconnection between adjacent instruments.
This ESM Cable Corp RG-142 coaxial cable is new and unused. It is open-box stock, meaning it may not be in its original retail packaging, but the cable itself is new and uninstalled. The connectors are clean with no wear, and the cable jacket shows no damage. Please view our photo set and contact us if you have any questions. Please note: We have multiple units in stock — yours may not be the one shown in the photos, however, it will be similar in condition and function.
Warranty Information
Additional Information
Brand: |
ESM Cable Corp |
Model: |
Z01037-005RB |
MPN: |
Z01037-005RB |
Type: |
Coaxial Cable Assembly |
SKU: |
32783 |
Cable Type: |
RG-142 |
Connector 1: |
N-Male (N-M) |
Connector 2: |
N-Female (N-F) |
Impedance: |
50 Ohm |
Cable Length: |
10 inches (approx. 25 cm) |
Seller Notes: |
New open-box cable assembly, part Z01037-005RB, label 13242 |
Country/Region of Manufacture: |
United States |
Form Factor: |
Flexible Cable Assembly |
Application: |
RF, Microwave, Test & Measurement |
Condition: |
New – Open Box |
Condition Notes: |
ESM Cable Corp RG-142 N-Male to N-Female coaxial cable is new and unused. Open-box — may not include original packaging. Cable and connectors are clean and uninstalled. Please contact us with any questions. |
