Edwards DP40 Multi Stage Dry Vacuum Pump with 2.2kW Alpak BS 5000 Motor 208/460V

Edwards DP40 Multi Stage Dry Vacuum Pump with 2.2kW Alpak BS 5000 Motor 208/460V

The Edwards DP40 is a multi-stage dry (oil-free) vacuum pump designed for industrial and scientific vacuum applications. Unlike oil-sealed rotary vane pumps, the DP40 uses a multi-stage claw or Roots-type dry pumping mechanism that generates vacuum without lubricating oil in the pumping chamber, making it suitable for clean, contamination-sensitive processes. This unit is driven by a GEC Electromotors Ltd Alpak B.S.5000 three-phase induction motor rated at 2.2 kW and is mounted on a welded steel cart frame with casters for easy repositioning on the shop floor.

Specifications & What's Included

• Manufacturer: Edwards High Vacuum (Crawley, Sussex, England)
• Model: DP40 Multi Stage Dry Pump
• Pump Type: Multi-stage dry (oil-free)
• Motor: GEC Electromotors Ltd Alpak Induction Motor B.S.5000, Size D90LC
• Motor Power: 2.2 kW
• Motor Speed: 3400 RPM
• Voltage: 208–230 / 460 VAC
• Current Draw: 8.9 / 8.0 / 4.0 A
• Phase: 3-Phase
• Frequency: 60 Hz
• Motor Duty Type: S1 (Continuous)
• Insulation Class: Class F
• Motor Enclosure: IP55
• Wiring Configuration: Y/YY (star/double-star for dual voltage)
• Overall Dimensions: 27" L x 15" W x 22" H
• Approximate Weight: 285 lbs
• Includes: Pump, motor, and welded steel wheeled cart frame

Applications

The Edwards DP series multi-stage dry vacuum pumps were developed for semiconductor fabrication, flat panel display manufacturing, chemical processing, and other clean-vacuum applications where oil contamination of the process is unacceptable. Introduced in the late 1980s and through the 1990s, the DP range was a key part of Edwards' push into dry pumping as semiconductor fabs began moving away from oil-sealed pumps to eliminate hydrocarbon backstreaming. The DP40 is used as a backing or booster pump in high-vacuum systems — commonly paired with a turbomolecular pump or Roots blower — and in direct-process pumping roles on CVD, PVD, etch, and implant equipment. The dry pumping mechanism also makes this type of pump widely used in pharmaceutical, food processing, and analytical instrument environments where clean vacuum is required. Edwards dry pumps of this series remain in service in legacy semiconductor and research facilities today and are a common target for refurbishment.
