Decision Data DSM 1937 G 13" Green Phosphor CRT Terminal No Logic Board 1993

Decision Data DSM 1937 G 13" Green Phosphor CRT Terminal No Logic Board 1993

The Decision Data DSM 1937 G is a 13-inch green phosphor CRT video display terminal manufactured in December 1993 in Taiwan. This listing is for the display unit only — the logic board is not included. The unit is rated for 120–230V operation at 50/60 Hz, making it compatible with both North American and international power standards.

Specifications & What's Included

• Manufacturer: Decision Data
• Model: DSM 1937 G
• Part Number: E000665460
• Screen Size: 13 inches (CRT)
• Display Type: Green phosphor CRT
• Voltage: 120–230V AC
• Current: 2.0–1.0A
• Frequency: 50/60 Hz
• Power Connector: IEC C13 inlet (rear)
• Date of Manufacture: December 1993
• Country of Manufacture: Taiwan R.O.C.
• Logic Board: Not included — display unit only
• Form Factor: Desktop/tabletop
• What's Included: Display unit only — no logic board, no cables, no mounting hardware

Applications

Decision Data produced display terminals primarily for use with IBM midrange computer systems — notably the IBM System/36, System/38, and AS/400 (iSeries) platforms — as well as their own proprietary office systems sold primarily into banking, insurance, and corporate data-entry environments during the 1980s and early 1990s. These terminals functioned as dumb or intelligent display stations, relying on a separate logic or controller board (or a standalone controller unit) to handle the host communication protocol, with the display unit providing the CRT screen, deflection circuitry, and power supply. The "No Logic" designation on this unit means the display housing and CRT are present, but the internal logic/controller board that handles the actual data communication has been removed — making it suitable as a parts or restoration source, a display prop, or a project for collectors restoring vintage terminal systems. By the mid-1990s, PC-based workstations had largely displaced dedicated ASCII and 5250/3270-type terminals in most business environments, making surviving examples of this era increasingly collectible among vintage computing enthusiasts.
