Cygnus Technology CDAT16 16-Channel SCSI Data Acquisition System 120VAC
A 16-channel SCSI-based data acquisition system designed for industrial and telecommunications testing and monitoring. The unit captures analog signals across 16 input channels and provides 16 output channels for signal generation and control applications.
Specifications & What's Included
- 16 analog input channels (BNC connectors)
- 16 output channels (BNC connectors)
- SCSI interface (50-pin Centronics, DB-25)
- Rackmount form factor
- 120VAC, 60Hz power requirement
- Front-mounted tape/floppy drive for data storage
- LCD alphanumeric front-panel display
- Trigger inputs and manual control buttons
- Unit only; no accessories confirmed
Applications
SCSI data acquisition systems of this type were used in telecommunications infrastructure testing, industrial process monitoring, and equipment diagnostics throughout the 1990s and 2000s. These units integrate with SCSI-equipped workstations and servers for real-time signal capture and post-acquisition analysis. Typical deployment includes telecommunications test benches, manufacturing quality control, and equipment condition monitoring systems where multi-channel simultaneous data capture was required.
This Cygnus Technology CDAT16 16-Channel SCSI Data Acquisition System has been inspected and powers on, as shown in the photo set. We were not able to test it further beyond powering it on, so its full operational status is not confirmed. The unit is in good cosmetic shape overall — the front panel, LCD display, BNC channel connectors, and tape drive area are clean and intact. The rear SCSI connector shows some light dust and minor oxidation on the housing, and the rear cooling fans show typical service use. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Cygnus Technology |
Model: |
CDAT16 |
MPN: |
CDAT16 |
Type: |
SCSI-Based Data Acquisition System |
SKU: |
35560 |
Number of Channels: |
16 |
Interface: |
SCSI |
Connector Type: |
SCSI (50-pin Centronics), DB-25 |
Form Factor: |
Rackmount |
Power Requirements: |
120VAC, 60Hz |
Storage Medium: |
Built-in tape/floppy drive (front-mounted) |
Display: |
LCD alphanumeric front-panel display |
Trigger Inputs: |
Trigger In, Trigger Out, Select, Manual |
Controls: |
Menu, Set, Execute, Search (EOD/File/Next), Start, Stop, Rewind, Unload |
Channel Configuration: |
16 analog input channels (BNC), 16 output channels (BNC) |
Condition: |
Used – Powers On, Not Fully Tested |
Seller Notes: |
Unit only; powers on. No accessories confirmed included. |
Condition Notes: |
Cygnus Technology CDAT16 16-Ch SCSI Data Acquisition System. Powers on; full function not tested. Good cosmetic condition. Rear SCSI connector shows minor oxidation. Sold as-is beyond power-on confirmation. |
