Condor HAA15-0.8-A+ DC Power Supply 15V 0.8A 12V 1A 100-240V Open Frame
The Condor HAA15-0.8-A+ is an open-frame, PCB-mount DC power supply made by Condor DC Power Supplies, Inc. (Oxnard, CA). It provides a selectable dual output — either ±15V DC at 0.8A or +12V DC at 1A — from a universal AC input covering 100 through 240 volts, making it suitable for use in a wide range of equipment worldwide. The open-frame format is designed for OEM integration directly into instrument enclosures or equipment chassis rather than standalone bench use.
Specifications & What's Included
- Model: HAA15-0.8-A+
- Manufacturer: Condor DC Power Supplies, Inc., Oxnard, CA
- Input Voltage: 100 / 120 / 215 / 230–240V AC (jumper-selectable per connection table)
- Input Current: 0.79 / 0.65 / 0.35 / 0.33A (varies by input tap selected)
- Input Frequency: 47–63Hz (derate 10% for operation below 58Hz)
- Output 1: ±15V DC @ 0.8A
- Output 2: +12V DC @ 1A
- Alternate Output: –5V DC @ 0.4A (achieved by jumpering E1–E2 and readjusting R57)
- Phase: Single phase
- Form Factor: Open frame / PCB mount
- Safety Certifications: UL Listed, CSA (Level 3)
- Country of Manufacture: Mexico
- Copyright / Production Date: 1990
- Unit only — no accessories included
Applications
Open-frame power supplies like the Condor HAA15-0.8-A+ are designed for OEM integration into scientific instruments, laboratory equipment, industrial controls, and other electronic systems where a compact, PCB-mountable DC supply is needed. Condor was a well-regarded supplier of open-frame and modular power supplies from the 1970s through the 1990s, and their products appeared widely in test and measurement gear, medical instruments, and embedded industrial systems of that era. The ±15V output is particularly common in analog signal-processing circuits and op-amp stages, where dual-rail supplies are a standard requirement. The universal input range means the supply can operate on both North American (120V) and European (240V) mains without modification beyond a jumper change, which made it a practical OEM choice for equipment sold internationally. Replacement units and spares for instruments originally equipped with these supplies continue to be sought by repair technicians and legacy equipment maintainers.
This Condor HAA15-0.8-A+ open-frame DC power supply has been inspected and appears to be in good condition. The unit shows normal wear consistent with prior use — the chassis and PCB are intact with no visible damage. The label and rating plate are clean and fully legible. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Condor |
Model: |
HAA15-0.8-A+ |
MPN: |
HAA15-0.8-A+ |
Type: |
Open Frame DC Power Supply |
SKU: |
32853 |
Input Voltage: |
100/120/215/230-240V AC |
Input Frequency: |
47–63Hz |
Output Voltage: |
±15V DC @ 0.8A or 12V DC @ 1A |
Output 1: |
±15V DC @ 0.8A |
Output 2: |
+12V DC @ 1A |
Number of Outputs: |
Dual (selectable) |
Form Factor: |
Open Frame / PCB Mount |
Phase: |
Single Phase |
Condition: |
Used – Inspected |
Country/Region of Manufacture: |
Mexico |
Seller Notes: |
Unit only; no accessories. Output also usable at -5V/0.4A by jumpering E1-E2 and readjusting R57. |
Safety Certifications: |
UL, CSA (Level 3) |
Year: |
1990 |
Condition Notes: |
Condor HAA15-0.8-A+ open-frame DC power supply. Inspected and in good used condition. Normal wear; chassis and PCB intact, label legible. Please view our photos and contact us with any questions. |
