Description
Compaq 288329-001 PS-5880-1 76W Power Supply Deskpro 4000N 100-240V
76W internal power supply unit designed for the Compaq Deskpro 4000N desktop computer. Converts AC input to multiple regulated DC output voltages for system operation.
Specifications & What's Included
- Model: PS-5880-1 (MPN 288329-001)
- Output Power: 76W
- Input: 100-240V AC, 50-60Hz
- Output Voltages: +5V, +3.5V, +12V, -12V, +5Vaux
- Proprietary multi-pin connector
- Internal cooling fan
- Includes attached power harness cable
- AC power cord not included
Applications
Used in Compaq Deskpro 4000N systems from the late 1990s. The Deskpro 4000N was a business-class desktop workstation platform. This supply unit provides the necessary power distribution for motherboard and component operation in compatible systems.
Condition: Used
This Compaq 288329-001 / PS-5880-1 76W Deskpro 4000N power supply is in used condition and has been inspected. The unit shows normal cosmetic wear consistent with prior installation. The rating label on the side is clean and fully legible. The output harness cable is included and appears intact. The proprietary multi-pin output connector is present and shows no visible damage. Please view our photo set and contact us if you have any questions.
This Compaq 288329-001 / PS-5880-1 76W Deskpro 4000N power supply is in used condition and has been inspected. The unit shows normal cosmetic wear consistent with prior installation. The rating label on the side is clean and fully legible. The output harness cable is included and appears intact. The proprietary multi-pin output connector is present and shows no visible damage. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Compaq |
Model: |
PS-5880-1 |
MPN: |
288329-001 |
Secondary Model: |
288328-001 |
Type: |
Desktop Computer Power Supply |
SKU: |
14088 |
Compatible With: |
Compaq Deskpro 4000N |
Maximum Output Power: |
76W |
Input Voltage: |
100-120V / 200-240V AC |
Input Current: |
2.5A / 1.25A |
Input Frequency: |
50-60Hz |
Output Voltages: |
+5V, +3.5V, +12V, -12V, +5Vaux |
Output Current +5V: |
5A |
Output Current +3.5V: |
7A |
Output Current +12V: |
1.5A |
Output Current -12V: |
0.2A |
Output Current +5Vaux: |
1.2A |
Form Factor: |
Proprietary (Compaq Deskpro) |
Connector Type: |
Proprietary multi-pin output connector |
Cooling: |
Internal fan |
Country/Region of Manufacture: |
China |
Condition: |
Used |
Seller Notes: |
Includes attached power harness cable. No AC power cord included. |
Condition Notes: |
Compaq 288329-001 PS-5880-1 76W Deskpro 4000N power supply. Used, inspected. Normal cosmetic wear. Output harness included. Proprietary connector intact. Contact us with questions. |
