Cirrus

Cirrus Logic CL-MD5650DT-SC-C 16-Bit ISA 33600bps Internal Voice Modem Audio

(No reviews yet) Write a Review
SKU:
32254
MPN:
CL-MD5650DT-SC-C
Condition:
Used
Availability:
Usually ships within 1-2 business days.
Weight:
1.00 LBS
Shipping:
Calculated at Checkout
  • Cirrus Logic CL-MD5650DT-SC-C 16-bit ISA voice modem card – front view showing bracket with RJ-11 port and audio jacks
  • Cirrus Logic CL-MD5650DT-SC-C ISA modem card – angled top view showing PCB components and ISA edge connector
  • Cirrus Logic CL-MD5650DT-SC-C modem card – reverse component side showing ISSI memory chips and additional ICs with board number 6C5IR21
  • Cirrus Logic CL-MD5650DT-SC-C ISA modem card – PCB back side showing FCC label 'Jaton Explorer 56' and 'Made in USA' sticker
  • Cirrus Logic CL-MD5650DT-SC-C modem card – close-up of PCB edge showing board number 6C5IR21 and ISA gold fingers
  • Cirrus Logic CL-MD5650DT-SC-C main controller chip close-up – chip markings: CL-MD5650DT-SC-C, 85052-950HR, 9828 A, TAIWAN-W
$15.00
Was: $30.00
Current Stock: 1

Sold Out

Description

Cirrus Logic CL-MD5650DT-SC-C 16-Bit ISA 33600bps Internal Voice Modem Audio Card

16-bit ISA internal modem card with integrated voice and audio capabilities. Supports 33.6 Kbps data transmission and connects via RJ-11 phone line interface.

Specifications & What's Included

  • Model: CL-MD5650DT-SC-C / 6C5IR21
  • Form Factor: 16-bit ISA card
  • Data Rate: 33600 bps (33.6 Kbps)
  • Interface: RJ-11 phone line with integrated audio jacks
  • Chipset: Cirrus Logic CL-MD5650DT-SC-C
  • Manufactured: Taiwan
  • FCC Compliant (Part 15)
  • Includes modem card only

Applications

This modem card was designed for 486 and early Pentium-era desktop PCs using ISA slots. Supported dial-up internet connectivity, fax transmission, and voice/audio functions common in business and consumer computing through the 1990s and early 2000s. Requires systems with available ISA slot and compatible drivers.

Condition: Used
This Cirrus Logic CL-MD5650DT-SC-C 16-bit ISA internal voice modem card has been inspected and appears to be in good used condition. The PCB is clean with no visible damage, cracked traces, or burnt components. The ISA gold edge connector looks intact, and the bracket-mounted RJ-11 and audio jacks appear undamaged. Normal light handling wear is present on the card. Please view our photo set and contact us if you have any questions.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
Cirrus Logic
Model:
CL-MD5650DT-SC-C
MPN:
CL-MD5650DT-SC-C
Secondary Model:
6C5IR21
Type:
Internal Voice Modem Card
SKU:
32254
Condition:
Used – Inspected
Seller Notes:
Includes modem card only. Inspected and in good condition.
Country/Region of Manufacture:
Taiwan
Form Factor:
ISA Card (16-bit)
Bus Interface:
ISA 16-bit
Data Rate:
33600 bps (33.6 Kbps)
Modem Type:
Voice Modem with Audio
Chipset:
Cirrus Logic CL-MD5650DT-SC-C
Chipset Part Number:
85052-950HR
Interface Type:
RJ-11 Phone Line
Audio Capability:
Yes – integrated audio jacks
FCC ID:
Jaton Explorer 56
PCB Revision:
9828 A
Compatible With:
ISA-slot desktop PCs, vintage 486/Pentium systems
Standards:
FCC Part 15 compliant
Condition Notes:
Cirrus Logic CL-MD5650DT-SC-C 16-bit ISA voice modem card. Inspected and in good used condition. PCB clean, ISA edge connector intact, RJ-11 and audio jacks undamaged. Normal light wear. Photos available.
View AllClose
