Carlon JLP-96 Water Meter 1-1/4" NPT Thread Positive Displacement USA

Carlon JLP-96 Water Meter 1-1/4" NPT Thread Positive Displacement USA

The Carlon JLP-96 is a positive displacement cold water meter manufactured by Carlon Meter Co. in Grand Haven, Michigan, USA. It features a polymer body with two 1-1/4" NPT male threaded ports for inline installation and a hinged top-mounted register housing with a U.S. gallons odometer dial and sweep pointer.

Specifications & What's Included

• Model: JLP-96
• Manufacturer: Carlon Meter Co., Grand Haven, Michigan, USA
• Thread Size: 1-1/4" NPT (National Pipe Thread)
• Measurement: U.S. Gallons
• Register: Odometer-style dial with sweep pointer, hinged protective lid
• Body Material: Polymer / plastic construction
• Serial Number: 2168615 (embossed on top housing)
• Odometer reading at photography: 1,186,980 U.S. gallons
• Meter only — no additional accessories included

Applications

The Carlon JLP-96 is a positive displacement water meter of the type used in residential and light commercial water utility metering applications. Positive displacement meters work by mechanically dividing the flow into precisely measured increments using an internal measuring chamber, making them well-suited for low-flow and intermittent-flow measurement where accuracy at varying flow rates matters. This style of meter — with NPT-threaded ports and a top-mounted register — was a common format for municipal utility metering and private well or irrigation system monitoring. Carlon Meter Co., based in Grand Haven, Michigan, was a recognized U.S. producer of plastic-bodied water meters. This unit is being sold as-is and would be suited for parts, display, or repair use.
