  • Nunome Electric NES-1000-TUV 1KVA dry-type transformer – front view showing toroidal core and DIN rail terminal blocks on top Nunome Electric NES-1000-TUV transformer – angled top-front view showing primary and secondary terminal block wiring

    Nunome Electric NES-1000-TUV Dry-Type Transformer 1KVA 200-240V 10A 50/60Hz

    Nunome Electric Co

    $100.00
    Was: $125.00
    Nunome Electric NES-1000-TUV Dry-Type Transformer 1KVA 200-240V 10A 50/60Hz Single-phase dry-type transformer manufactured by Nunome Electric Co., Ltd. Converts 200–240V AC input to 100V AC output at...
    48440
    SKU:
    48440
    Availability:
    Usually ships within 1-2 business days.
    Weight:
    42.00 LBS
    Brand:
    Nunome Electric Co., Ltd.
    Model:
    NES-1000-TUV
    MPN:
    NES-1000-TUV
    SKU:
    48440
    Condition:
    Used – Inspected
    Seller Notes:
    Dry-type transformer with terminal block connections included.
    Country of Manufacture:
    Japan
    Form Factor:
    Open Frame / Panel Mount
    Power Rating:
    1 kVA
    Primary Voltage:
    200V / 220V / 230V / 240V AC
    Secondary Voltage:
    100V AC
    Current Rating:
    10A
    Frequency:
    50/60 Hz
    Phase:
    Single Phase
    Impedance:
    2.2 / 2.3% (at 25°C)
    Enclosure Rating:
    IP00
    Insulation Class:
    Class B (ta50°C)
    Certifications:
    TUV
    Transformer Type:
    Dry-Type
    PRI Circuit Breaker Rating:
    600V 15A EN 60947-2
    SEC Circuit Breaker Rating:
    600V 10A EN 60947-2
    Terminal Connection:
    DIN Rail Terminal Block
    Power Requirements:
    200-240V AC, 50/60Hz
    Condition Notes:
    This Nunome Electric NES-1000-TUV 1KVA dry-type transformer has been inspected and shows normal cosmetic wear consistent with prior use. The core, frame, and DIN rail terminal blocks appear intact with no visible damage.
