Black Box ME728A 150-0528-103 8-Port Async Line Driver Multiplexer DB25 RS-232

Black Box ME728A 150-0528-103 8-Port Async Line Driver Multiplexer DB25 RS-232

The Black Box ME728A is an 8-port asynchronous line driver multiplexer designed to extend and concentrate multiple RS-232 serial data streams over a shared link. Identified on the unit as the LD-478, it multiplexes up to eight asynchronous serial channels — each on a DB25 interface — onto a single transmission path, making it well-suited for connecting clusters of terminals, printers, or other serial devices to a host system or data switch across longer distances than standard RS-232 allows. The unit houses its logic and power supply in a compact black desktop enclosure and is configurable via internal DIP switch banks.

Specifications & What's Included

• Manufacturer: Black Box Corporation
• Model: ME728A (also labeled LD-478 on front panel)
• Part Number: 150-0528-103
• Number of Channels: 8 asynchronous serial ports
• Connector Type: DB25 (25-pin) per channel
• Signal Standard: RS-232 asynchronous serial
• Input Voltage: 115V AC
• Current Draw: 1.2A
• Frequency: 50/60 Hz
• Form Factor: Desktop enclosure
• Country of Manufacture: Puerto Rico – USA
• Certifications: UL listed, CSA listed
• FCC Compliance: Part 15 Class A
• Internal DIP switches: Switch Selection (standalone / Micro500 mode, distance select, dynamic/RCVD control), RTS/DTR Select per channel, RCVD Control per channel, loopback per channel
• Channel terminals visible on internal connector row: T1, R1, T2, R2, T3, R3, T4, R4, T5, R5, T6, R6, T7, R7, T8, R8, TX, RX, EM, SL, DLB
• Internal power supply module housed in vented metal sub-chassis
• Attached AC power cord included
