Description
Bay Networks Communications Processor Board v4.00 111316-3213 MACH130
VME/Backplane-form communications processor board designed for Bay Networks routing and switching systems. Features AMD MACH130-15JC-18JT CPLD controller and supporting signal processing ICs for packet handling and network communication tasks.
Specifications & What's Included
- Model: 111316-3213 | Firmware: v4.00
- Main Controller: AMD MACH130-15JC-18JT CPLD
- Form Factor: VME/Backplane card module
- Manufactured in Malaysia
- Board only; no accessories included
Applications
This processor board type was used in Bay Networks enterprise routing and switching equipment from the 1990s through early 2000s. Communications processor boards handle packet forwarding, protocol processing, and inter-module communication in modular network appliances. Compatible with Bay Networks chassis-based systems requiring VME-form factor processing modules. Typically found in core routing infrastructure and data center network equipment of that era.
This Bay Networks Communications Processor Board v4.00 (part 111316-3213) has been visually inspected and appears to be in good used condition. The PCB is clean and intact with no visible cracked traces, broken components, or physical damage. Board markings, ICs, and connectors all appear undamaged. Some light handling marks are present, consistent with prior installation and removal from a chassis. This is a board-only unit — no additional accessories or cables are included. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Bay Networks |
Model: |
111316-3213 |
MPN: |
111316-3213 |
Secondary Model: |
v4.00 |
Type: |
Communications Processor Board |
SKU: |
14789 |
Form Factor: |
Card / Module (VME/Backplane) |
Firmware Version: |
v4.00 |
Main Controller / CPLD: |
AMD MACH130-15JC-18JT (CPLD) |
Notable ICs: |
4995 106399 A, 4995 106377 A, 4995 106347 D |
PCB Marking: |
Bay Networks, Inc. |
Condition: |
Used – Inspected |
Seller Notes: |
Board only; no accessories included. |
Country/Region of Manufacture: |
Malaysia (per IC markings) |
Condition Notes: |
Bay Networks Communications Processor Board v4.00 111316-3213. Visually inspected; PCB clean and intact, no cracked traces or broken components. Light handling marks from prior use. Board only, no accessories. Please contact us with questions. |
