Asus SPAX-M Socket 7 Motherboard Rev 1.01 PCI ISA HP Pavilion 4440 System Board

Asus SPAX-M Socket 7 Motherboard Rev 1.01 PCI ISA HP Pavilion 4440 System Board

The Asus SPAX-M is a Socket 7 system board originally installed in the HP Pavilion 4440 desktop computer. Board revision REV:1.01 is clearly marked on the PCB silkscreen. It features the Socket 7 ZIF CPU socket, onboard I/O, and a combination of PCI and ISA expansion slots typical of mid-1990s ATX-era desktop platforms.

Specifications & What's Included

• Make / Model: Asus SPAX-M
• Board Revision: Rev 1.01
• CPU Socket: Socket 7 (ZIF) — compatible with Intel Pentium, AMD K6, and Cyrix 6x86 processors
• Expansion Slots: 3× PCI, 2× ISA
• Memory Slots: SIMM slots (visible in photos)
• Onboard I/O: 1× Parallel port (DB-25), 2× Serial ports (DB-9), PS/2 ports
• Storage Headers: IDE and floppy drive headers present
• Crystal Oscillator: 32.768 MHz (visible on PCB)
• Form Factor: Baby-AT / compact desktop
• Originally installed in: HP Pavilion 4440 desktop system
• Board only — no CPU, RAM, or accessories included

Applications

The Socket 7 platform was the dominant PC desktop standard from roughly 1993 through the late 1990s, supporting a wide range of processors from Intel (Pentium 75–233 MHz), AMD (K5, K6, K6-2), and Cyrix (6x86, MII). HP used OEM-configured Asus boards like the SPAX-M in its Pavilion consumer desktop line during the mid-to-late 1990s. This board is suitable for restoring or repairing an HP Pavilion 4440 system, retro PC building, or vintage computing projects. The combination of PCI and ISA slots makes it compatible with a broad range of period-correct expansion cards — sound cards, video cards, modems, and SCSI adapters from the era commonly used these bus types. Socket 7 also marked the final generation of the shared Intel/AMD/Cyrix CPU socket before each manufacturer diverged onto proprietary platforms, making it a historically significant and well-supported form factor among retro computing enthusiasts.
