Analog Devices 31-710008-001 Digital Board Rev X.5 VME Card D1238 Assy
The Analog Devices 31-710008-001 is a digital controller board (Assembly D1238, Revision X.5) designed for use in VME-format instrumentation and industrial control systems. The board features a dual-row card-edge connector configuration consistent with VME/Eurocard architecture and mounts via an integrated front panel bracket for rack or chassis installation. It incorporates a Synertek SY6522A Versatile Interface Adapter (VIA) as its primary controller IC — a well-known parallel/serial I/O handler used extensively in precision instrumentation designs of this era.
Specifications & What's Included
- Manufacturer: Analog Devices
- Part Number / MPN: 31-710008-001
- Assembly Number: D1238
- Revision: Rev X.5
- Board Type: Digital PCB / Controller Card
- Form Factor: VME / Eurocard-style module with front panel bracket
- Primary Controller IC: Synertek SY6522A Versatile Interface Adapter (VIA)
- Additional ICs visible: MC74HC112N, MC74HC00AN, MM74HC244N (logic/buffer ICs)
- Edge connectors: dual large card-edge connectors on opposing sides of the board
- On-board passive components: electrolytic and ceramic capacitors, resistor arrays (RN series), diodes
- Includes: board only with integrated front panel bracket; no additional accessories observed
Applications
Analog Devices produced digital interface and controller boards of this type for integration into their proprietary signal processing, data acquisition, and industrial automation systems. VME-form digital boards in this class typically handle parallel I/O, digital control logic, and system timing within a larger multi-card chassis. The SY6522A VIA at the core of this board was commonly used to manage bidirectional parallel ports, timers, and handshake-based data transfer between subsystems. This board would be of interest to engineers maintaining legacy Analog Devices instrumentation platforms, researchers supporting vintage VME-based control systems, or repair facilities sourcing digital I/O cards for compatible equipment.
This Analog Devices 31-710008-001 Digital Board (Assy D1238, Rev X.5) is new and unused. The board is in clean, uninstalled condition with no signs of prior use. It may be out of its original packaging. Please view our photo set and contact us if you have any questions.
