Description
Allied AL-A300ATX 300W ATX Desktop PC Power Supply 115/230V 20-Pin SATA
Used ATX form factor desktop power supply with 300W maximum output and dual voltage input (115/230V AC). Includes output harness with SATA and Molex connectors.
Specifications & What's Included
- Model: AL-A300ATX
- Power Output: 300W max (280W combined DC)
- Input: 115/230V AC, 50/60Hz
- Outputs: +3.3V/+5V/+12V/-12V/-5V/+5VSB
- Connectors: 20-pin ATX, SATA, 4-pin Molex, Floppy
- Cooling: Rear-mounted 80mm thermal control fan
- Certifications: UL, CSA, TUV, FCC, CE
Applications
Designed for standard ATX desktop PC builds using Socket 478/775 era motherboards and compatible systems. Common in business desktop environments through the 2000s and 2010s. Supports legacy floppy connectors and SATA/Molex peripheral power.
Please note: We may have multiple units of this item in stock. The unit you receive may vary slightly from the one shown in the photos. All units are functionally equivalent and inspected to the same standard.
Condition: Used
This Allied AL-A300ATX 300W ATX Desktop Power Supply has been inspected and appears to be in good used condition. The chassis shows typical light surface wear consistent with prior use, and the label is clean and fully legible. The output harness, including SATA and Molex connectors, is intact and undamaged. The unit has not been bench-tested at our facility, but was pulled from a working desktop computer environment. Please view our photo set and contact us if you have any questions.
This Allied AL-A300ATX 300W ATX Desktop Power Supply has been inspected and appears to be in good used condition. The chassis shows typical light surface wear consistent with prior use, and the label is clean and fully legible. The output harness, including SATA and Molex connectors, is intact and undamaged. The unit has not been bench-tested at our facility, but was pulled from a working desktop computer environment. Please view our photo set and contact us if you have any questions.
Warranty Information
We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose
Additional Information
Brand: |
Allied |
Model: |
AL-A300ATX |
MPN: |
AL-A300ATX |
SKU: |
18948 |
Condition: |
Used – Inspected |
Seller Notes: |
Power supply only; harness with SATA and Molex connectors included |
Form Factor: |
ATX Desktop |
Power Output: |
300W Max (Combined 280W) |
AC Input Voltage: |
115/230V AC |
AC Input Current: |
8A @ 115V / 4A @ 230V |
Input Frequency: |
50/60 Hz |
Output +3.3V: |
28A |
Output +5V: |
30A (Peak 10A) |
Output +12V: |
15A |
Output -12V: |
0.8A |
Output -5V: |
0.3A |
Output +5VSB: |
2A |
Combined +3.3V/+5V Power: |
180W |
Combined +12V Power: |
9.6W (per label) |
Max DC Combined Power: |
280W |
Connector Type: |
20-Pin ATX Main, SATA, 4-Pin Molex, Floppy |
Cooling: |
Thermal control fan (rear-mounted 80mm) |
Power Requirements: |
115/230V AC, 50/60Hz, 8A/4A |
Certifications: |
UL, CSA, TUV, FCC, CE |
Compatible With: |
ATX desktop PC cases; standard ATX motherboards |
Country of Manufacture: |
China |
Condition Notes: |
Allied AL-A300ATX 300W ATX power supply in good used condition. Inspected; chassis shows light wear. Output harness intact with SATA and Molex connectors. Not bench-tested; pulled from working desktop environment. |
