Description
Allen-Bradley N-3406-2-H00AA Servo Motor 230V 6000RPM 6.2 LB-IN 0.5" Shaft
The Allen-Bradley N-3406-2-H00AA is an AC servo motor from Rockwell Automation's N Series, designed for precision motion control applications requiring high-speed, high-accuracy rotary output. It runs on 230V AC and spins to 6000 RPM, delivering 6.2 LB-IN of continuous torque through a 0.5-inch keyed output shaft. Connections are made through two top-mounted multi-pin circular connectors — one for power and one for feedback — a configuration typical of Allen-Bradley's integrated-encoder servo motors.
Specifications & What's Included
- Model: N-3406-2-H00AA
- Catalog Number: 193527, Series B
- Code: G002285
- Voltage: 230V AC
- Speed: 6000 RPM
- Torque: 6.2 LB-IN
- Shaft Diameter: 0.5 in (12.7 mm)
- Shaft Length: 1.1 in (27.9 mm)
- Connectors: Dual top-mount circular multi-pin (power and feedback)
- Mounting: Flange-mount
- Motor body only — no cables, drive, or mounting hardware included
Applications
Allen-Bradley N Series servo motors are used in factory automation and CNC machine tool systems where precise speed and position control are required. They pair with compatible Allen-Bradley or Rockwell Automation servo drives (such as the 1391 and Ultra series) and are commonly found in machine tools, packaging machinery, assembly lines, and robotics. The dual-connector design integrates both power delivery and encoder feedback in a compact flange-mount package, making these motors well suited for retrofit and OEM motion control builds. Allen-Bradley's N Series dates from the 1980s and 1990s and remains in active use in legacy automation systems that are still running on original drives and controllers.
This Allen-Bradley N-3406-2-H00AA servo motor was pulled from a working system and is in good used condition overall. One of the two top-mount electrical connector lock-rings is chipped, as visible in our photos. No cables are included — the motor ships by itself. Please review our full photo set and contact us with any questions before purchasing.
Warranty Information
Additional Information
Brand: |
Allen-Bradley |
Model: |
N-3406-2-H00AA |
MPN: |
N-3406-2-H00AA |
Secondary Model: |
G002285 |
SKU: |
51803 |
Type: |
AC Servo Motor |
Voltage Rating: |
230V |
Speed (RPM): |
6000 RPM |
Torque Rating: |
6.2 LB-IN |
Shaft Diameter: |
0.5 in (12.7 mm) |
Shaft Length: |
1.1 in (27.9 mm) |
Connector Type: |
Circular multi-pin (dual top-mount connectors) |
Number of Connectors: |
2 |
Series: |
N Series |
Hardware Revision: |
B |
Form Factor: |
Flange-mount |
Country/Region of Manufacture: |
United States |
Compatible With: |
Allen-Bradley servo drives, Rockwell Automation systems |
Seller Notes: |
Motor only — no cables included. |
Condition Notes: |
This Allen-Bradley N-3406-2-H00AA servo motor was pulled from a working system. One electrical connector lock-ring is chipped. No cables included. Motor only. Please view photos and contact us with any questions. |
