Gateway 6001761 56K Internal Fax Modem PCI Card D-1156IVB2/B1 PN 17510 Rev 7

Gateway 6001761 56K Internal Fax Modem PCI Card D-1156IVB2/B1 PN 17510 Rev 7

The Gateway 6001761 is a 56K internal PCI fax/modem card, model D-1156IVB2/B1, board part number 17510 Rev 7. It installs into a standard PCI slot and provides dial-up voice, fax, and data connectivity via a standard RJ-11 phone line connection. The card is built around a Broadcom controller and is FCC and Industry Canada certified for home or office use.

Specifications & What's Included

• Gateway Part Number: 6001761
• Model: D-1156IVB2/B1
• Board Part Number: 17510, Rev 7
• Type: 56K Internal PCI Fax/Modem
• Bus Interface: PCI
• Data Rate: 56 Kbps
• Connector: RJ-11 phone jack on bracket
• Chipset: Broadcom
• Country of Manufacture: China
• FCC ID: DK4 CHN-35561-M5-E; FCC Part 15 & 68 compliant
• Industry Canada Certification: 1030 11055A
• Includes: modem/phone cable

Applications

56K PCI internal modem cards like this one were standard equipment in desktop PCs of the late 1990s and early 2000s, providing dial-up internet access, fax transmission, and data transfer over standard public switched telephone networks (PSTN). This card follows the V.90/V.92 generation of modem standards, which were the last major dial-up standards before broadband internet displaced dial-up as the dominant home and office connection type. Today these cards still see use in legacy desktop systems, point-of-sale terminals, and industrial or remote monitoring applications that rely on POTS (plain old telephone service) lines for low-bandwidth data or fax communication. The card was sold as a Gateway OEM part for installation in Gateway desktop computers of that era but fits any standard PCI-equipped PC.
